Circuit Realizations


In total, 457 circuit realizations are available at RevLib. You can download all circuits at once using the following link:
Download all circuits
Alternatively, single access to every circuit is provided below. This list can also be refined according to a respective gate library.



    Lib. lines gates costs File Pic. Ref. Realizes
1 EQ 15 384 384 Download realization No picture available D. Michael Miller A 64-bit adder
2 EQ 15 305 305 Download realization Show realization MDS:2005 A form of integer adder.
3 EQ 15 192 192 Download realization No picture available D. Michael Miller A 32-bit adder
4 EQ 15 96 96 Download realization Show realization D. Michael Miller A 16-bit adder
5 EQ n.a. 74 74 Download realization Show realization MDS:2005 0410184
6 EQ 15 48 48 Download realization Show realization D. Michael Miller An 8-bit adder
7 EQ 3 10 10 Download realization Show realization GWDD:2008 3_17
8 EQ 5 9 9 Download realization Show realization GWDD:2008 Decod24
9 EQ 5 9 9 Download realization Show realization GWDD:2008 Decod24
10 EQ 5 9 9 Download realization Show realization GWDD:2008 Decod24
11 EQ 5 9 9 Download realization Show realization GWDD:2008 Decod24
12 EQ 3 8 8 Download realization Show realization GWDD:2008 Miller gate
13 EQ 4 7 7 Download realization Show realization GWDD:2008 Toffoli (double)
14 EQ 3 7 7 Download realization Show realization GWDD:2008 Fredkin gate
15 EQ 3 5 5 Download realization Show realization Tof:80 Toffoli gate
16 EQ 5 5 5 Download realization Show realization MDS:2005 Graycode (over 6 variables)
17 EQ 3 4 4 Download realization Show realization GWDD:2008 Peres gate
