graph class More...

#include <Graph.h>

Inheritance diagram for GOPPRR::CGraph:

Collaboration diagram for GOPPRR::CGraph:

Public Member Functions
	CGraph (const ::std::string &OID="", const ::std::string &Type="", const ::std::string &ID="", const std::map< ::std::string,::GOPPRR::CProperty * > &Properties=std::map< ::std::string,::GOPPRR::CProperty * >(), const std::vector< ::GOPPRR::CBinding > &BindingSet=std::vector< ::GOPPRR::CBinding >(), const std::vector< ::GOPPRR::CGraphicalContainer > &Containers=std::vector< ::GOPPRR::CGraphicalContainer >(), const std::map< std::string,::GOPPRR::CObject * > &ObjectSet=std::map< std::string,::GOPPRR::CObject * >(), const std::map< std::string,::GOPPRR::CPort * > &PortSet=std::map< std::string,::GOPPRR::CPort * >(), const std::map< std::string,::GOPPRR::CRelationship * > &RelationshipSet=std::map< std::string,::GOPPRR::CRelationship * >(), const std::map< std::string,::GOPPRR::CRole * > &RoleSet=std::map< std::string,::GOPPRR::CRole * >()) throw ()
	general constructor
	CGraph (const CGraph &Source) throw ()
	copy constructor
::std::map< ::std::string, GOPPRR::CObject * >	Contained (GOPPRR::CObject *const pObject, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CObject * >	Container (GOPPRR::CObject *const pObject, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CObject * >	Objects (GOPPRR::CPort const pPort, GOPPRR::CRole const pRole, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CObject * >	Objects (GOPPRR::CRole *const pRole, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CObject * >	Objects (GOPPRR::CRole *const pRole, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CObject * >	Objects (const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
CGraph &	operator= (const CGraph &Source) throw ()
	assignment operator
::std::map< ::std::string, GOPPRR::CPort * >	Ports (GOPPRR::CRole *const pRole, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CPort * >	Ports (GOPPRR::CObject *const pObject, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CPort * >	Ports (GOPPRR::CObject *const pObject, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CProperty * >	Properties (const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRelationship * >	Relationships (GOPPRR::CRole *const pRole, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRelationship * >	Relationships (GOPPRR::CRole *const pRole, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CObject *const pObject, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CObject *const pObject, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CObject const pObject, GOPPRR::CPort const pPort, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CRelationship *const pRelationship, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CObject const pObject, GOPPRR::CPort const pPort, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CRelationship *const pRelationship, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
::std::map< ::std::string, GOPPRR::CRole * >	Roles (GOPPRR::CRole *const pRole, const ::std::string &Type, const bool &bSubString=false, const bool &bUseException=true) const throw (::GOPPRR::Error::CEmpty)
	abstraction method
virtual	~CGraph () throw ()
	destructor

Public Attributes
::std::vector< GOPPRR::CBinding >	m_BindingSet
	set of bindings in a graph
::std::vector < GOPPRR::CGraphicalContainer >	m_Containers
	graphical containments in a graph
::std::string	m_ID
	(literal) identifier of element
::std::map< std::string, GOPPRR::CObject * >	m_ObjectSet
	set of objects in a graph
::std::string	m_OID
	unique object identifier
::std::map< std::string, GOPPRR::CPort * >	m_PortSet
	set of ports
::std::map< std::string, GOPPRR::CProperty * >	m_Properties
	properties of non-properties
::std::map< std::string, GOPPRR::CRelationship * >	m_RelationshipSet
	set of relationships in a graph
::std::map< std::string, GOPPRR::CRole * >	m_RoleSet
	role set of a graph
::std::string	m_Type
	name of a type

Detailed Description

graph class

Definition at line 52 of file Graph.h.

Constructor & Destructor Documentation

GOPPRR::CGraph::CGraph	(	const ::std::string &	OID = `""`,
		const ::std::string &	Type = `""`,
		const ::std::string &	ID = `""`,
		const std::map< ::std::string,::GOPPRR::CProperty * > &	Properties = `std::map< ::std::string, ::GOPPRR::CProperty* >()`,
		const std::vector< ::GOPPRR::CBinding > &	BindingSet = `std::vector< ::GOPPRR::CBinding >()`,
		const std::vector< ::GOPPRR::CGraphicalContainer > &	Containers = `std::vector< ::GOPPRR::CGraphicalContainer >()`,
		const std::map< std::string,::GOPPRR::CObject * > &	ObjectSet = `std::map< std::string, ::GOPPRR::CObject* >()`,
		const std::map< std::string,::GOPPRR::CPort * > &	PortSet = `std::map< std::string, ::GOPPRR::CPort* >()`,
		const std::map< std::string,::GOPPRR::CRelationship * > &	RelationshipSet = `std::map< std::string, ::GOPPRR::CRelationship* >()`,
		const std::map< std::string,::GOPPRR::CRole * > &	RoleSet = `std::map< std::string, ::GOPPRR::CRole* >()`
	)		throw ()

general constructor

Parameters

[in]	OID	object identifier
[in]	Type	literal name of the type
[in]	ID	identifier
[in]	Properties	set of property references
[in]	BindingSet	set of bindings
[in]	Containers	set of graphical containers
[in]	ObjectSet	set of objects
[in]	PortSet	set of ports
[in]	RelationshipSet	set of relationships
[in]	RoleSet	set of roles

Definition at line 37 of file Graph.cpp.

GOPPRR::CGraph::CGraph ( const CGraph & Source ) throw ()

copy constructor

Parameters

[in] Source source object to copy

Definition at line 54 of file Graph.cpp.

GOPPRR::CGraph::~CGraph ( ) throw ()

virtual

destructor

Definition at line 71 of file Graph.cpp.

Member Function Documentation

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Contained	(	GOPPRR::CObject *const	pObject,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all objects graphical contained by a another one in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 1049 of file Graph.cpp.

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Container	(	GOPPRR::CObject *const	pObject,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all objects which graphical contain another one in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 992 of file Graph.cpp.

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Objects	(	GOPPRR::CPort *const	pPort,
		GOPPRR::CRole *const	pRole,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all objects connected to a certain port and role in a certain graph.

Parameters

[in]	pPort	pointer to the port
[in]	pRole	pointer to the role
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 776 of file Graph.cpp.

Referenced by oETCS::GEN::CCPPGenerator::GenerateControlFlows(), oETCS::GEN::CCPPGenerator::GenerateLanguage(), and oETCS::GEN::CCPPGenerator::GenerateTransitions().

Here is the caller graph for this function:

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Objects	(	GOPPRR::CRole *const	pRole,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all objects connected to a certain role in a certain graph.

Parameters

[in]	pRole	pointer to the role
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 833 of file Graph.cpp.

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Objects	(	GOPPRR::CRole *const	pRole,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets certain types of objects connected to a certain role in a certain graph.

Parameters

[in]	pRole	pointer to the role
[in]	Type	object type
[in]	bSubString	if true, Type only must be a substring of object type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 890 of file Graph.cpp.

std::map<::std::string, GOPPRR::CObject * > GOPPRR::CGraph::Objects	(	const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets certain types of objects in a certain graph.

Parameters

[in]	Type	object type
[in]	bSubString	if true, Type only must be a substring of object type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to objects

Definition at line 953 of file Graph.cpp.

References m_ObjectSet.

GOPPRR::CGraph & GOPPRR::CGraph::operator= ( const CGraph & Source ) throw ()

assignment operator

Parameters

[in] Source object instance to assign from

Definition at line 1088 of file Graph.cpp.

References m_BindingSet.

std::map<::std::string, GOPPRR::CPort * > GOPPRR::CGraph::Ports	(	GOPPRR::CRole *const	pRole,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all ports connected to a certain role in a certain graph.

Parameters

[in]	pRole	pointer to the role
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to ports

Definition at line 606 of file Graph.cpp.

std::map<::std::string, GOPPRR::CPort * > GOPPRR::CGraph::Ports	(	GOPPRR::CObject *const	pObject,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all ports connected to a certain object in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to ports

Definition at line 663 of file Graph.cpp.

std::map<::std::string, GOPPRR::CPort * > GOPPRR::CGraph::Ports	(	GOPPRR::CObject *const	pObject,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets certain types of ports connected to a certain object in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	Type	port type
[in]	bSubString	if true, Type only must be a substring of port type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to ports

Definition at line 720 of file Graph.cpp.

std::map<::std::string, GOPPRR::CProperty * > GOPPRR::CNonProperty::Properties	(	const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

inherited

abstraction method

Gets certain properties of a non-property object

Parameters

[in]	Type	property type
[in]	bSubString	if true, Type only must be a substring of property type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to properties

Definition at line 90 of file NonProperty.cpp.

Referenced by oETCS::GEN::CCPPGenerator::GenerateDataFlow(), oETCS::GEN::CCPPGenerator::GenerateEVCTransitions(), oETCS::GEN::CCPPGenerator::GenerateFunctionBlockElements(), oETCS::GEN::CCPPGenerator::GenerateLanguage(), and oETCS::GEN::CCPPGenerator::GenerateRootGraph().

Here is the caller graph for this function:

std::map<::std::string, GOPPRR::CRelationship * > GOPPRR::CGraph::Relationships	(	GOPPRR::CRole *const	pRole,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all relationships connected to a certain role in a certain graph.

Parameters

[in]	pRole	pointer to the role
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to relationships

Definition at line 485 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRelationship * > GOPPRR::CGraph::Relationships	(	GOPPRR::CRole *const	pRole,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets certain types of relationships connected to a certain role in a certain graph.

Parameters

[in]	pRole	pointer to the role
[in]	Type	relationship type
[in]	bSubString	if true, Type only must be a substring of relationship type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to relationships

Definition at line 542 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CObject *const	pObject,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all roles connected to a certain object in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 81 of file Graph.cpp.

Referenced by oETCS::GEN::CCPPGenerator::GenerateControlFlows(), and oETCS::GEN::CCPPGenerator::GenerateLanguage().

Here is the caller graph for this function:

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CObject *const	pObject,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets certain roles connected to a certain object in a certain graph.

Parameters

[in]	pObject	pointer to the object
[in]	Type	role type
[in]	bSubString	if true, Type only must be a substring of role type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 138 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CObject *const	pObject,
		GOPPRR::CPort *const	pPort,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all roles connected to a certain port and object in a certain graph.

Parameters

[in]	pPort	pointer to the port
[in]	pObject	pointer to the object
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 201 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CRelationship *const	pRelationship,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all roles connected to a certain relationship in a certain graph.

Parameters

[in]	pRelationship	pointer to the relationship
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 258 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CObject *const	pObject,
		GOPPRR::CPort *const	pPort,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all certain types of roles connected to a certain port and object in a certain graph.

Parameters

[in]	pPort	pointer to the port
[in]	pObjectt	pointer to the object
[in]	Type	role type
[in]	bSubString	if true, Type only must be a substring of role type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 308 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CRelationship *const	pRelationship,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all certain types of roles connected to a certain relationship in a certain graph.

Parameters

[in]	pRelationship	pointer to the relationship
[in]	Type	role type
[in]	bSubString	if true, Type only must be a substring of role type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 371 of file Graph.cpp.

std::map<::std::string, GOPPRR::CRole * > GOPPRR::CGraph::Roles	(	GOPPRR::CRole *const	pRole,
		const ::std::string &	Type,
		const bool &	bSubString = `false`,
		const bool &	bUseException = `true`
	)		const throw (::GOPPRR::Error::CEmpty)

abstraction method

Gets all certain types of roles connected to a certain another role in a certain graph. This skips the navigation via the related relationship.

Parameters

[in]	pRole	pointer to the role
[in]	Type	role type
[in]	bSubString	if true, Type only must be a substring of role type
[in]	bUseException	optional boolean flag for throwing a exception in case of an empty map

Returns: map of pointers to roles

Definition at line 427 of file Graph.cpp.

Member Data Documentation

::std::vector< GOPPRR::CBinding > GOPPRR::CGraph::m_BindingSet

set of bindings in a graph

Set of bindings in a graph.

Definition at line 373 of file Graph.h.

Referenced by operator=().

::std::vector< GOPPRR::CGraphicalContainer > GOPPRR::CGraph::m_Containers

graphical containments in a graph

Definition at line 420 of file Graph.h.

::std::string GOPPRR::CNonProperty::m_ID

inherited

(literal) identifier of element

Definition at line 103 of file NonProperty.h.

Referenced by oETCS::GEN::CMain::Execute(), oETCS::GEN::CBuildGenerator::Generate(), oETCS::GEN::CVMGenerator::Generate(), oETCS::GEN::CCPPGenerator::GenerateCommunication(), oETCS::GEN::CCPPGenerator::GenerateEVCTransitions(), oETCS::GEN::CVMGenerator::GeneratePSM(), and GOPPRR::CNonProperty::operator=().

::std::map< std::string,GOPPRR::CObject* > GOPPRR::CGraph::m_ObjectSet

set of objects in a graph

Set of objects in a graph indexed by their OID.

Definition at line 383 of file Graph.h.

::std::string GOPPRR::CConcept::m_OID

inherited

unique object identifier

Definition at line 78 of file Concept.h.

Referenced by oETCS::GEN::CCPPGenerator::BuildAbstractModel(), oETCS::GEN::CCPPGenerator::GenerateCommunication(), oETCS::GEN::CCPPGenerator::GenerateDataFlow(), oETCS::GEN::CCPPGenerator::GenerateDataFlowForCommunication(), oETCS::GEN::CCPPGenerator::GenerateEVCTransitions(), oETCS::GEN::CCPPGenerator::GenerateLanguage(), oETCS::GEN::CCPPGenerator::GenerateRootGraph(), oETCS::GEN::CCPPGenerator::GenerateTransitions(), GOPPRR::CConcept::operator=(), and oETCS::UT::CGOPPRRTransformer::TestCreateSyntax().

::std::map< std::string,GOPPRR::CPort* > GOPPRR::CGraph::m_PortSet

set of ports

Set of ports indexed by their OID.

Definition at line 393 of file Graph.h.

Referenced by oETCS::GEN::CCPPGenerator::GenerateCommunication(), oETCS::GEN::CCPPGenerator::GenerateFunctionBlock(), oETCS::GEN::CCPPGenerator::GenerateFunctionBlockElements(), and oETCS::GEN::CCPPGenerator::GenerateLanguage().

::std::map< std::string,GOPPRR::CProperty* > GOPPRR::CNonProperty::m_Properties

inherited

properties of non-properties

Properties of non-properties indexed by their OID

Definition at line 113 of file NonProperty.h.

Referenced by oETCS::GEN::CCPPGenerator::GenerateLanguage().

::std::map< std::string,GOPPRR::CRelationship* > GOPPRR::CGraph::m_RelationshipSet

set of relationships in a graph

Set of relationships in a graph indexed by their OID

Definition at line 403 of file Graph.h.

Referenced by oETCS::GEN::CCPPGenerator::GenerateCommunication(), oETCS::GEN::CCPPGenerator::GenerateControlFlows(), oETCS::GEN::CCPPGenerator::GenerateDataFlow(), oETCS::GEN::CCPPGenerator::GenerateDataFlowForCommunication(), oETCS::GEN::CCPPGenerator::GenerateEVCTransitions(), oETCS::GEN::CCPPGenerator::GenerateFunctionBlock(), and oETCS::GEN::CCPPGenerator::GenerateTransitions().

::std::map< std::string,GOPPRR::CRole* > GOPPRR::CGraph::m_RoleSet

role set of a graph

Role set of a graph indexed by their OID.

Definition at line 413 of file Graph.h.

Referenced by oETCS::GEN::CCPPGenerator::BuildAbstractModel(), oETCS::GEN::CCPPGenerator::GenerateCommunication(), oETCS::GEN::CCPPGenerator::GenerateControlFlows(), oETCS::GEN::CCPPGenerator::GenerateDataFlow(), oETCS::GEN::CCPPGenerator::GenerateEVCTransitions(), oETCS::GEN::CCPPGenerator::GenerateFunctionBlock(), oETCS::GEN::CCPPGenerator::GenerateLanguage(), and oETCS::GEN::CCPPGenerator::GenerateTransitions().

::std::string GOPPRR::CConcept::m_Type

inherited

name of a type

Definition at line 85 of file Concept.h.

Referenced by oETCS::GEN::CCPPGenerator::GenerateControlFlows(), oETCS::GEN::CCPPGenerator::GenerateDataFlowForCommunication(), oETCS::GEN::CCPPGenerator::GenerateLanguage(), and oETCS::GEN::CCPPGenerator::GenerateTransitions().

The documentation for this struct was generated from the following files:

Public Member Functions

Public Attributes

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
